MCN-SF - NPT Male Connector | Tube Fittings
MCN-SF NPT Connector SF  sold by Titanfittings.com


Stainless Tube Fitting Male Pipe NPT


Material: 316 Stainless Steel
Bar Stock: ASTM A479, ASTM A276
Forging: ASTM B164
MCN-SF - Male NPT Connector

Item# Item Name Our Price Qty Add
MC-1-1N-SF MC-01-01N-SF - 1/16" Tube x 1/16" Male NPT Connector - Single Ferrule Stainless | Tube Fittings
$10.59
MC-1-2N-SF MC-01-02N-SF - 1/16" Tube x 1/8" Male NPT Connector - Single Ferrule Stainless | Tube Fittings
$10.78
MC-2-2N-SF MC-02-02N-SF - 1/8" Tube x 1/8" Male NPT Connector - Single Ferrule Stainless | Tube Fittings
$9.67
MC-2-4N-SF MC-02-04N-SF - 1/8" Tube x 1/4" Male NPT Connector - Single Ferrule Stainless | Tube Fittings
$9.67
MC-2-6N-SF MC-02-06N-SF - 1/8" Tube x 3/8" Male NPT Connector - Single Ferrule Stainless | Tube Fittings
$11.64
MC-2-8N-SF MC-02-08N-SF - 1/8" Tube x 1/2" Male NPT Connector - Single Ferrule Stainless | Tube Fittings
$14.58
MC-3-2N-SF MC-03-02N-SF - 3/16" Tube x 1/8" Male NPT Connector - Single Ferrule Stainless | Tube Fittings
$9.46
MC-3-4N-SF MC-03-04N-SF - 3/16" Tube x 1/4" Male NPT Connector - Single Ferrule Stainless | Tube Fittings
$9.67
MC-4-2N-SF MC-04-02N-SF - 1/4" Tube x 1/8" Male NPT Connector - Single Ferrule Stainless | Tube Fittings
$8.34
MC-4-4N-SF MC-04-04N-SF- 1/4" Tube x 1/4" Male NPT Connector - Single Ferrule Stainless | Tube Fittings
$10.50
MC-4-6N-SF MC-04-06N-SF - 1/4" Tube x 3/8" Male NPT Connector - Single Ferrule Stainless | Tube Fittings
$10.02
MC-4-8N-SF MC-04-08N-SF - 1/4" Tube x 1/8" Male NPT Connector - Single Ferrule Stainless | Tube Fittings
$12.55
MC-4-12N-SF MC-04-12N-SF - 1/4" Tube x 3/4" Male NPT Connector - Single Ferrule Stainless | Tube Fittings
$16.18
MC-5-2N-SF MC-05-02N-SF - 5/16" Tube x 1/8" Male NPT Connector - Single Ferrule Stainless | Tube Fittings
$9.67
MC-5-4N-SF MC-05-04N-SF - 5/16" Tube x 1/4" Male NPT Connector - Single Ferrule Stainless | Tube Fittings
$9.67
MC-5-6N-SF MC-05-06N-SF - 5/16" Tube x 3/8" Male NPT Connector - Single Ferrule Stainless | Tube Fittings
$10.36
MC-6-2N-SF MC-06-02N-SF - 3/8" Tube x 1/8" Male NPT Connector - Single Ferrule Stainless | Tube Fittings
$10.69
MC-6-4N-SF MC-06-04N-SF - 3/8" Tube x 1/4" Male NPT Connector - Single Ferrule Stainless | Tube Fittings
$10.69
MC-6-6N-SF MC-06-06N-SF - 3/8" Tube x 3/8" Male NPT Connector - Single Ferrule Stainless | Tube Fittings
$11.27
MC-6-8N-SF MC-06-08N-SF - 3/8" Tube x 1/2" Male NPT Connector - Single Ferrule Stainless | Tube Fittings
$13.49
MC-6-12N-SF MC-06-12N-SF - 3/8" Tube x 3/4" Male NPT Connector - Single Ferrule Stainless | Tube Fittings
$17.83
MC-8-16N-SF MC-08-016N-SF - 1/2" Tube x 1" Male NPT Connector - Single Ferrule Stainless | Tube Fittings
$27.25
MC-8-2N-SF MC-08-02N-SF - 1/2" Tube x 1/8" Male NPT Connector - Single Ferrule Stainless | Tube Fittings
$16.27
MC-8-4N-SF MC-08-04N-SF - 1/2" Tube x 1/4" Male NPT Connector - Single Ferrule Stainless | Tube Fittings
$14.42
MC-8-6N-SF MC-08-06N-SF- 1/2" Tube x 3/8" Male NPT Connector - Single Ferrule Stainless | Tube Fittings
$14.90
MC-8-8N-SF MC-08-08N-SF - 1/2" Tube x 1/2" Male NPT Connector - Single Ferrule Stainless | Tube Fittings
$16.47
MC-8-12N-SF MC-08-12N-SF - 1/2" Tube x 3/4" Male NPT Connector - Single Ferrule Stainless | Tube Fittings
$21.09
MC-10-12N-SF MC-10-12N-SF - 5/8" Tube x 3/4" Male NPT Connector - Single Ferrule Stainless | Tube Fittings
$22.21
MC-10-6N-SF MC-10-6N-SF - 5/8" Tube x 3/8" Male NPT Connector - Single Ferrule Stainless | Tube Fittings
$16.66
MC-10-8N-SF MC-10-8N-SF - 5/8" Tube x 1/2" Male NPT Connector - Single Ferrule Stainless | Tube Fittings
$17.27
MC-12-12N-SF MC-12-12N-SF - 3/4" Tube x 3/4" Male NPT Connector - Single Ferrule Stainless | Tube Fittings
$24.73
MC-12-16N-SF MC-12-16N-SF - 3/4" Tube x 1" Male NPT Connector - Single Ferrule Stainless | Tube Fittings
$36.08
MC-12-8N-SF MC-12-8N-SF - 3/4" Tube x 1/2" Male NPT Connector - Single Ferrule Stainless | Tube Fittings
$23.33
MC-14-12N-SF MC-14-12N-SF - 7/8" Tube x 3/4" Male NPT Connector - Single Ferrule Stainless | Tube Fittings
$40.77
MC-14-16N-SF MC-14-16N-SF - 7/8" Tube x 1" Male NPT Connector - Single Ferrule Stainless | Tube Fittings
$42.26
MC-16-12N-SF MC-16-12N-SF - 1" Tube x 3/4" Male NPT Connector - Single Ferrule Stainless | Tube Fittings
$44.65
MC-16-16N-SF MC-16-16N-SF - 1" Tube x 1" Male NPT Connector - Single Ferrule Stainless | Tube Fittings
$44.65
MC-16-8N-SF MC-16-8N-SF - 1" Tube x 1/2" Male NPT Connector - Single Ferrule Stainless | Tube Fittings
$44.65
MC-20-16N-SF MC-20-16N-SF - 1 1/4" Tube x 1" Male NPT Connector - Single Ferrule Stainless | Tube Fittings
$88.19
MC-20-20N-SF MC-20-20N-SF - 1 1/4" Tube x 1 1/4" Male NPT Connector - Single Ferrule Stainless | Tube Fittings
$84.28
MC-24-24N-SF MC-24-24N-SF - 1 1/2" Tube x 1 1/2" Male NPT Connector - Single Ferrule Stainless | Tube Fittings
$164.63
MC-32-32N-SF MC-32-32N-SF - 2" Tube x 2" Male NPT Connector - Single Ferrule Stainless | Tube Fittings
$244.97
Check the items you wish to purchase, then click


Features:
Tube Fitting Material: 316 Stainless Steel



Product Details:
Pressure Ratings:
Tube O.D.
(inch)
TUBE WALL THICKNESS (inch)
0.010 0.012 0.014 0.016 0.020 0.028 0.035 0.049 0.065 0.083 0.095 0.109 0.120
1/16 5600 6800 8100 9400 12000
1/8 8500 10900
3/16 5400 7000 10200
1/4 4000 5100 7500 10200
5/16 4000 5800 8000
3/8 3300 4800 6500
1/2 2600 3700 5100 6700
5/8 2900 4000 5200 6000
3/4 2400 3300 4200 4900 5800
7/8 2000 2800 3600 4200 4800
1 2400 3100 3600 4200 4700
= Tubing working pressure (psi)
Dimensional Drawings:
CONNECTS FRACTIONAL TUBE TO FEMALE NPT THREAD
Tube O.D.TdWidth Across Flat
Part No.D (inch)(NPT)Minh (inch)H (inch)ABIL
MCN 1-1N1/161/161.275/165/168.6310.922023.83
MCN 1-2N1/161/81.277/167/168.6310.9222.3526.23
MCN 2-2N1/81/82.287/167/1612.715.2423.8730.48
MCN 2-4N2/81/42.289/167/1612.715.2428.9535.56
MCN 2-6N2/83/82.2811/167/1612.715.2429.2135.81
MCN 2-8N2/81/22.287/87/1612.715.2435.5642.16
MCN 3-2N3/161/83.047/161/213.711624.6331.24
MCN 3-4N3/161/43.049/161/213.711629.7136.32
MCN 4-2N1/41/84.821/29/1615.2417.7825.432.76
MCN 4-4N1/41/44.829/169/1615.2417.7830.4837.84
MCN 4-6N1/43/84.8211/169/1615.2417.7830.9838.35
MCN 4-8N1/41/24.827/89/1615.2417.7837.3344.7
MCN 4-12N1/43/44.821-1/169/1615.2417.7838.8646.22
MCN 5-2N5/161/84.829/165/816.2518.5426.6734.03
MCN 5-4N5/161/46.359/165/816.2518.5431.2438.6
MCN 5-6N5/163/86.3511/165/816.2518.5431.7539.11
MCN 6-2N3/81/84.825/811/1616.7619.327.9435.3
MCN 6-4N3/81/47.115/811/1616.7619.332.5139.87
MCN 6-6N3/83/87.1111/1611/1616.7619.332.5139.87
MCN 6-8N3/81/27.117/811/1616.7619.338.8646.22
MCN 6-12N3/83/47.111-1/1611/1616.7619.340.3847.75
MCN 8-2N1/21/84.8213/167/822.8621.8428.738.86
MCN 8-4N1/21/47.1113/167/822.8621.8433.2743.43
MCN 8-6N1/23/89.6513/167/822.8621.8433.2743.43
MCN 8-8N1/21/210.417/87/822.8621.8438.8649.02
MCN 8-12N1/23/410.411-1/167/822.8621.8440.3850.54
MCN 8-16N1/2110.411-3/87/822.8621.8446.9957.15
MCN 10-6N5/83/89.6515/16124.3821.8434.0344.19
MCN 10-8N5/81/211.9315/16124.3821.8438.8649.02
MCN 10-12N5/83/412.71-1/16124.3821.8440.3850.54
MCN 12-8N3/41/211.931-1/161-1/824.3821.8440.3850.54
MCN 12-12N3/43/415.741-1/161-1/824.3821.8440.3850.54
MCN 12-16N3/4115.741-3/81-1/824.3821.8446.9957.15
MCN 14-12N7/83/415.741-3/161-1/425.921.8440.3850.54
MCN 14-16N7/8118.281-3/81-1/425.921.8446.9957.15
MCN 16-8N11/211.931-3/81-1/231.2426.4145.2157.4
MCN 16-12N13/415.741-3/81-1/231.2426.4145.2157.4
MCN 16-16N1122.351-3/81-1/231.2426.4150.0362.23
MCN 20-16N1-1/4122.351-3/41-7/841.1538.8655.1277.22
MCN 20-20N1-1/41-1/427.691-3/41-7/841.1538.8655.1277.22
MCN 24-24N1-1/21-1/234.042-1/82-1/450.0445.2161.7288.9
MCN 32-32N2245.972-3/4367.5662.7476.2113.54
Competitor Cross Reference:
COMPETITOR PART NUMBER
ITEM #SWAGELOKSSP DUOLOKPARKER A-LOK
MCN 1-1NSS-100-1-1ISSD1MCN11MSC1N-SS
MCN 1-2NSS-100-1-2ISSD1MCN21MSC2N-SS
MCN 2-2NSS-200-1-2ISSD2MCN22MSC2N-SS
MCN 2-4NSS-200-1-4ISSD2MCN42MSC4N-SS
MCN 2-6NSS-200-1-6ISSD2MCN62MSC6N-SS
MCN 2-8NSS-200-1-8ISSD2MCN82MSC8N-SS
MCN 3-2NSS-300-1-2ISSD3MCN23MSC2N-SS
MCN 3-4NSS-300-1-4ISSD3MCN43MSC4N-SS
MCN 4-2NSS-400-1-2ISSD4MCN24MSC2N-SS
MCN 4-4NSS-400-1-4ISSD4MCN44MSC4N-SS
MCN 4-6NSS-400-1-6ISSD4MCN64MSC6N-SS
MCN 4-8NSS-400-1-8ISSD4MCN84MSC8N-SS
MCN 4-12NSS-400-1-12ISSD4MCN124MSC12N-SS
MCN 5-2NSS-500-1-2ISSD5MCN25MSC2N-SS
MCN 5-4NSS-500-1-4ISSD5MCN45MSC4N-SS
MCN 5-6NSS-500-1-6ISSD5MCN65MSC6N-SS
MCN 6-2NSS-600-1-2ISSD6MCN26MSC2N-SS
MCN 6-4NSS-600-1-4ISSD6MCN46MSC4N-SS
MCN 6-6NSS-600-1-6ISSD6MCN66MSC6N-SS
MCN 6-8NSS-600-1-8ISSD6MCN86MSC8N-SS
MCN 6-12NSS-600-1-12ISSD6MCN126MSC12N-SS
MCN 8-2NSS-810-1-2ISSD8MCN28MSC2N-SS
MCN 8-4NSS-810-1-4ISSD8MCN48MSC4N-SS
MCN 8-6NSS-810-1-6ISSD8MCN68MSC6N-SS
MCN 8-8NSS-810-1-8ISSD8MCN88MSC8N-SS
MCN 8-12NSS-810-1-12ISSD8MCN128MSC12N-SS
MCN 8-16NSS-810-1-16ISSD8MCN168MSC16N-SS
MCN 10-6NSS-1010-1-6ISSD10MCN610MSC6N-SS
MCN 10-8NSS-1010-1-8ISSD10MCN810MSC8N-SS
MCN 10-12NSS-1010-1-12ISSD10MCN1210MSC12N-SS
MCN 12-8NSS-1210-1-8ISSD12MCN812MSC8N-SS
MCN 12-12NSS-1210-1-12ISSD12MCN1212MSC12N-SS
MCN 12-16NSS-1210-1-16ISSD12MCN1612MSC16N-SS
MCN 14-12NSS-1410-1-12ISSD14MCN1214MSC12N-SS
MCN 14-16NSS-1410-1-16ISSD14MCN1614MSC16N-SS
MCN 16-8NSS-1610-1-8ISSD16MCN816MSC8N-SS
MCN 16-12NSS-1610-1-12ISSD16MCN1216MSC12N-SS
MCN 16-16NSS-1610-1-16ISSD16MCN1616MSC16N-SS
MCN 20-16NSS-2000-1-16ISSD20MCN1620MSC16N-SS
MCN 20-20NSS-2000-1-20ISSD20MCN2020MSC20N-SS
MCN 24-24NSS-2400-1-24ISSD24MCN2424MSC24N-SS
MCN 32-32NSS-3200-1-32ISSD32MCN3232MSC32N-SS
